ORIC OR-A3 DTF DIGITAL HEAT TRANSFER PRINTING MACHINE

ORIC OR-A3 DTF DIGITAL HEAT TRANSFER PRINTING MACHINE

RM30,000.00
Earn 30,000 PY Reward Points

1 in stock (can be backordered)

Purchase this product now and earn 30,000 PY Reward Points (RM1,500.00)!
SKU: 095/OR-A3/UNIT Categories: , Tags: , , Brand:

Direct to Film Comprehensive Solution

Parameter
Print Head: Dual F1080 print heads.
Max Print Size: 300MM Print Width.
Print Speed: 4pass 7.1 sqm/h
Colors : CMYKLcLm + W
Feature
DTF-Mini320 is a new generation of the digital revolution, creating a new digital dtf film printing process. It makes up for the shortcomings of the existing dtf technology. The max printing width with 33mm roll to roll . Max print speed up to 7.1m2/h.

Technical Specifications:-

T-shirt Digital Heat Transfer Printing Machine
Model OR-A3 Mini330 DTF
Print Head 2 F1080 Print Heads
Printing Technology Piezoelectric Inkjet
Acceptable Media Width 320 mm
Thickness Maximum 39 mil(1 mm)
Printing Width ≤ 300 mm
Ink Cartridges Type Transfer Pigment Ink
Capacity Color Siphon+Regular stirring of white ink
Color CMYKLcLm + W
Applicable Medium Transfer film
Color Manage ICC or density curve
Media Heating System Powder & color fixing machine
Interface RJ-45/LAN
RIP Software Main top / Photoprint
Power Supply 50HZ/60HZ,220V/110V/10A
Environment Temperature 22℃ to 28℃
Humidity 40% to 70%
Printer Dimensions(With Stand) L950mm*W600mm*H550mm
Weight 95kg



Shaking Powder and Color Fix Machine
Model A3 Power Shaker
Media Width 0-300mm
Applicable Medium Nylon, Chemical Fiber, Cotton, Leather, Swimwear, Wetsuit, PVC, EVA, etc.
Powder Control Powder shake control, powder control, powder direction and volume control
Heating & Drying Function Multi-stage heating system, drying, cold air fan function
Rewind Function Automatic induction winding
Electrical Parameters Rated Voltage: 220V            Rated Current: 20A
Rated Power: 2KW              Power Consumption: 1KW-1.5KW
Packing Size & Weight Standard: L850* W670* H670mm
G.W: 115kg   N.W: 90kg
Power Shaker Dimensions Standard (Take-up Systems): L950* W550* H550mm

Additional Information

Weight 210 kg
